Power of Trust: Nepal’s #1 Genset brand
Kirloskar Portable Gensets come from the house of Kirloskar, having more than seven decades of experience. Kirloskar Green and Kirloskar Chhota Chilli have over 1 million Gensets in service across the globe.
Benefit of Compact Footprint
Kirloskar Portable Gensets are specially designed to fit in the smallest footprint area. With optimised fitment of components Kirloskar Portable Gensets take less space and provides you ample opportunity to expand. The Kirloskar Portable Genset fits in any of your application whether it is bungalows or petrol pumps; restaurants or Offices and hotels or clinics. With reduction in length or width (max of 1.6 ft), Kirloskar Portable Gensets genset becomes ideal for use in real estate, ATMs, offices etc. saving huge rental costs.
| Prime Rating at rated rpm ( as per ISO8528)1 | kVA | 5 | 7.5 | 10 | 12.5 | |
| kW | 4 | 6 | 8 | 10 | ||
| Genset Model | KG1-5AS3 | KG1-7.5AS4 | KG1-10AS5 | KG1-12.5AS2 | ||
| Frequency | Hz | 50 | ||||
| Power factor | lagging | 0.8 | ||||
| Voltage | V | 230 (1Ø) & 415 (3Ø) | ||||
| Governing class (As per ISO 8528 Part-V) | G2 | |||||
| Noise level | dBA | < 75 | ||||
| Fuel Consumption* | At 100% Load | Ltrs/hr | 1.60 | 2.21 | 3.00 | 3.45 |
| At 75% Load | 1.30 | 1.62 | 2.40 | 2.65 | ||
| At 50% Load | 1.0 | 1.21 | 1.80 | 1.94 | ||
| Fuel tank capacity | Ltrs | 50 | 50 | 50 | 50 | |
| Weight of genset with canopy (approx.)^ | Dry | Kg | 670 | 680 | 750 | 840 |
| Wet | Kg | 720 | 730 | 800 | 890 | |
| Overall dimensions of genset^ | Length | mm | 1310 | 1310 | 1760 | 1760 |
| Width | mm | 810 | 810 | 820 | 820 | |
| Height | mm | 1330 | 1330 | 1330 | 1330 | |
| Electrical Battery starting voltage | Volts-DC | 12 | ||||
| ENGINE | ||||||
| Engine Model | EA10 G1 | EA10 G1 | EA16 G1 | EA16 G1 | ||
| Rated output (Prime Continuous rating as per ISO 8528-1) |
kW | 7.3 | 7.3 | 11.8 | 11.8 | |
| HP | 10 | 10 | 16 | 16 | ||
| Cooling System | Air | |||||
| No. of cylinder | Number | 1 | 1 | 2 | 2 | |
| Cubic capacity | Ltrs | 0.95 | 0.95 | 1.56 | 1.56 | |
| Bore x Stroke | mm | 102 x 116 | 102 x 116 | 95 x 110 | 95 x 110 | |
| Rated Speed | RPM | 1500 | 1500 | 1500 | 1500 | |
| Aspiration | NA/TC/TA | NA | NA | NA | NA | |
| Lube Oil change period | Hrs | 500 hrs | ||||
| Lube Oil Sump Capacity | Ltrs | 3.5 | 3.5 | 6.5 | 6.5 | |
| Coolant Capacity | Ltrs | NA | NA | NA | NA | |
| ALTERNATOR | ||||||
| Insulation Class | Class H | |||||
| Alternator Efficiency (at 100% load) 0.8 pf** | % | 78.1 | 82.5 | 82.6 | 84.9 | |
| Max Voltage Dip at Full Load 0.8 pf Lag | Sec | < 20% | ||||
| Max Time to build up rated voltage at Rated RPM | < 5 sec provided engine reach the rated speed | |||||
