| Model | EHM |
| Batch Capacity | 200 Litres (7 Cu.ft) |
| Input Batch Capacity | 280 Litres (10 Cu.ft) |
| Engine (Optional) | 10 Hp Air Cooled Diesel Engine |
| Motor (Optional) | 10 Hp Electric Motor |
| Hopper Tipping | Mechanical operated wire rope type |
| Loading Hopper | Heavy duty made of 10 guage sheet |
| Mixing Drum | Heavy Duty drum with bearing and M.S. blade |
| Chassis | M.S. Fabiracted Chassis |
| Wheels | Pneumatic Wheels supported with M.S. Jacks |
| Hoist Trolley | Hoist Trolley |
| Tower | Made of ISMC 100 X 50 mm for height up to 20 meters |
| Additional Height | Can be obtained with angle tie supported by column every 3 meters |
